Specifications :

• MFG Part Number : CF4-SO632-34
• Product Group: CF4-SO
• Material: Stainless Steel; 400 Series
• Finish: Passivated
• Thread Type: Imperial
• Thread Size: 6-32 UNC
• Thread Code: 632
• Hole Diameter: 0.213 +0.003 -0.000
• Sheet Thickness: 0.04
• Dim A: 0.212 +0.000 -0.005
• Dim C: 0.156 ±0.005
• Dim D: 0.437 ±0.010
• Dim H Nom.: 0.25
• Dim L: 1.062 +0.002 -0.005
• CL to Edge Distance: 0.27
• .050in SS Recommended Tightening Torque: 8.75 in-lbs
• .050in SS Installation Force: 9500 lbs
• .050in SS Push Out: 647 lbs
• .050in SS Torque Out: 30 in-lbs
• .050in SS Pull Through: 680 lbs
