Specifications :

• MFG Part Number : CF4-SO3.5M3-14
• Product Group: CF4-SO
• Material: Stainless Steel; 400 Series
• Finish: Passivated
• Thread Type: Metric
• Thread Size: M3x0.5
• Thread Code: M3
• Hole Diameter: 5.41 +0.08 -0.00
• Sheet Thickness: 1
• Dim A: 5.39 +0.00 -0.13
• Dim C: 3.20 ±0.13
• Dim D: 4.00 ±0.25
• Dim H Nom.: 6.4
• Dim L: 14.00 +0.05 -0.13
• CL to Edge Distance: 6.8
• 1.300mm 300 Series Stainless Steel Recommended Tig: 0.55 N-m
• 1.300mm 300 Series Stainless Steel Installation Fo: 42.3 kN
• 1.300mm 300 Series Stainless Steel Push Out: 2877 N
• 1.300mm 300 Series Stainless Steel Torque Out: 3.06 N-m
• 1.300mm 300 Series Stainless Steel Pull Through: 3025 N
